 NAME£º CAP
 MATERIAL£ºA234-WPB.A420-WPL6.A234-WP5,A234-WP9,A234-WP11,A234-WP12,A234-WP91. A403-WP304.A403-WP304L.A403-WP316.A403-WP316L.A860-WPHY42,A860-WPHY46,A860-WPHY52,A860-WPHY60,A860-WPHY65,A860-WPHY70,A860-WPHY80
 SIZE£º1/2"-48",DN15-DN1200
 PRESSURE£ºSch5-Sch160,STD,XS,XXS,PN4.0,PN8.0,PN10.0,PN16.0
 STANDARDS£º ISO. ANSI. JIS. DIN GB/T12459,GB/T13401,ASME B16.9,SH3408 SH3409,HG/T21635,HG/T21631,SY/T0501,MSS SP-97
 USE£º Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc.
PRODUCT DRAWING PRODUCT CONSTRUCTION






Nominal pipe size
 DN
Outside Diameter at Bevel


Length


Limiting Wall
Thickness for
length E
Series A Series B E E1
15 21.3 18 25 - -
20 26.9 25 25 - -
25 33.7 32 38 - -
32 42.4 38 38 - -
40 48.3 45 38 - -
50 60.3 57 38 44 5.5
65 76.1(73) 76 38 51 7.0
80 88.9 89 51 64 7.6
90 101.6 - 64 76 8.1
100 114.3 108 64 76 8.6
125 139.7 133 76 89 9.5
150 168.3 159 89 102 11.0
200 219.1 219 102 127 12.7
250 273.0 273 127 152 12.7
300 323.9 325 152 178 12.7
350 355.6 377 165 191 12.7
400 406.4 426 178 203 12.7
450 457.2 478 203 229 12.7
500 508.0 529 229 254 12.7
550 559 -

254
600 610 630

267
650 660 - 267
700 711 720

267

 ¡¡
750 762 -

267

 ¡¡
800 813 820 267 ¡¡
850 864 - 267 ¡¡
900 914 920 267 ¡¡
950 965 - 305 ¡¡
1000 1016 1020 305 ¡¡
1050 1067 - 305 ¡¡
1100 1118 1120 343 ¡¡
1150 1168 - 343 ¡¡
1200 1220 1220 343 ¡¡
¡¡
